The
nuclei of human cells contain 22 autosomes
and 2 sex chromosomes. In females, the sex
chromosomes are the 2 X chromosomes. Males have one X chromosome
and one Y chromosome. A human karyotype
is shown with the sex chromosomes in the lower right corner.
1. |
3. |
![]() 4. |
1. The human X and Y chromosome, showing
structure and relative size.
2. The human X and Y chromosome stained with fluorescent dye and viewed under a fluorescense microscope. 3. An idiogram of the human X and Y chromosome, showing banding patterns and relative size. 4. An idiogram of the human Y chromosome showing general structure, position of pseudoautosomal regions, and the locus of the SRY gene. |
2. |
The
importance of the pseudoautosomal regions is that, because of the homology
between the pseudoautosomal regions, the X and Y chromosomes can synapse
during meiosis. As a result, the sex chromosomes will segregate during
anaphase in the same orderly way as homologous pairs of autosomes do. What
would happen if the X and Y chromosome did not share regions of homology
and therefore could not synapse? This image, courtesy
of C. Tease of Harvard University, shows synapsis of the X and Y chromosomes
of a mouse during prophase of meiosis I.
How does the
presence of pseudoautosomal regions on the Y chromosome suggest a hypothesis
about the aberrant phenotype in Turner's Syndrome ?
As you know already, the X-Y system of sex determination is found
in many kinds of organisms besides mammals. The fruit fly, Drosophila,
uses such a system as do a number of plants that have separate sexes (e.g.,
Cannabis sativa, the source of hemp and marijuana). A similar system is
found in birds and moths, but here the male has two of the same chromosome
(designated ZZ), whereas the female has "heterogametic" chromosomes (designated
Z and W).
Also as you know by now, the female sexual phenotype is the default developmental pathway. In order to get a male 2 things must happen:
1. the female developmental pathway must be "turned off".If either of these steps fails, the embryo will develop as a female. It is the genes on the Y chromosome which control these steps. The presence of the Y chromosome is therefore decisive for unleashing the developmental program that leads to a baby boy.
2. the male developmental pathway must be "turned on".
The key player in this latter group is SRY (for
sex-determining
regionY) . In older studies
it is referred to as TDF (testis
determining
factor),
but they are the same gene. SRY is a 35 kb (kilobase)
gene located on the short (p) arm of the Y just outside the pseudoautosomal
region. It is
the master switch that triggers the events that converts the embryo into
a male. Without
this gene (and the Y chromosome which it), a female develops.
On the other hand, with the Y chromosome and the SRY gene, a male develops
even if there are 2 X chromosomes (XXY) or 3 X chromosomes (XXXY).
Other holandric genes on the Y chromosome
Ten years ago the human Y chromosome was thought to be a small genetic wasteland with only one important gene (SRY) which determined sexual development. However, research at the Whitehead Institute for Biomedical Research in 1997 began to reverse this unflattering picture of the Y. These results are not only generating a new respect for the Y chromosome but also could lead to novel diagnostic techniques for thousands of infertile men. The results also have profound implications for understanding the genetic differences between men and women and the genetic underpinnings of chromosomal disorders such as Turner syndrome.
In the October 24, 1997 issue of Science, Page and Lahn report that a systematic search of the Y chromosome yielded 12 novel genes in the NRY region of the Y (the non-recombining region region of the Y is not homologous to any region on the X chromosome, so there is no recombination or exchange genetic material between the two). Along with eight previously identified genes, the 12 novel genes compose a substantial, nearly comprehensive catalog of genes found in the NRY, which constitutes 95 percent of the Y chromosome.
The 12 new genes, and six of the eight previously discovered Y chromosome
genes, can be sorted into two categories:
"These results show that the Y chromosome is functionally coherent;
it has a short list of missions to which it is dedicated. By
contrast, other human chromosomes contain motley assortments of genes with
no theme or unifying purpose apparent. The human Y chromosome is
a striking exception” says Professor Page.
Mutation and Translocation of the SRY locus |
An interesting
example of the expression of SRY is the two mice in this photograph.
Both have an
XX karyotype
and thus should be female, but they have the male sexual phenotype instead.
This is because they were engineered to have the SRY gene! Mouse
ova were fertilized in vitro, and XX zygotes were injected with DNA carrying
the SRY gene. These zygotes were implanted in a surrogate mother.
These 2 pseudo-males were the result.
Although these XX mice have testes, male sex hormones, and normal male
mating behavior, they are sterile.
|
![]()
|
